    POE PSE Media Converter With External power supply

    POE PSE Media Converter With External power supply


    Features

    with PoE support, to save power infrascture cost

    IEEE 802.3af/at PoE PSE (power source equipment) compatible

    Connect to PoE switches, mid-span hubs, or other 802.3af power source equipment (PSE).

    Support full-duplex and auto-negotiation mode for fiber port

    Stand alone unit with mini design


    10/100BaseT/TX to 100BaseFX Power over Ethernet (PoE) devices that serve as Power Sourcing Equipment (PSE),which allows the converter to provide power to IEEE802.3af /at PoE standard-compliant Powered Devices (PDs) using the twisted pair connection. Power transmitted along with data in one single cable (RJ45) allows you to expand your network where there are no power lines or outlets, where you wish to fix devices such as Wifi -Aps, IP Cameras or IP Phones, etc.


    Specifications

    Specifications
    Technology
    Network Standards

    IEEE802.3i 10BASE-T

    IEEE802.3u 100BASE-TX

    IEEE802.3x Flow Control

    Fiber Type

    ·Multi-Mode(MM):62.2/125m,50/125m

    ·Single mode(SM) 9/125m

    ·Cable:UPT cat.5 or higher

    Distance

    ·Multi-mode &Dual Fiber:2km,

    ·Single mode &single Fiber:15/30/50/80/120km

    Data Rate·10/100Mbps
    Connector·RJ45,SC,FCC
    Wavelength·1310nm,1550nm
    Diagnostic LED·Power, Link, Activity
    Power DC·48V,1.25A
    Power Consumption·≤3W
    Temperature·0-50℃(operating),-20-70℃(storage)
    Humidity

    ·10-90% non-condensing


    Dimension·88x49x21mm


    Ordering Information

    FR- PSE330 ,10/100 Mbps PoE PSE media converter

    FR-PSE330G-at 10/100/1000Mbps POE media converter, IEEE802.3af,15.4W

    FR-PSE330G-at 10/100/1000Mbps POE media converter, IEEE802.3at,25.5W
